| Testing Data | Position |
| Testing Range ( mm ) | 300mm 400mm 500mm 600mm 700mm 800mm 900mm 1000mm |
| Output Signal | 4~20mA 20~4mA(Minimum /Max load: 0/500Ω) |
| Supply voltage | 24VDC (-15% ~ + 20%) |
| Working current | <70mA |
| Polarity protection | Over-load protection up to -30VDC |
| Maximum pressure protection | 33VDC |
| Resolution | 16-bit D / A |
| Nonlinearity | ± 0.1% FS ± 0.3% FS |
| Update time | Analog signal 0.5mS (travel <1000mm) |
| Operating temperature | -40 ~ +85 ºC |
| Storage temperature | -40 ~ +100 ºC |
| Temperature effect | <0.007% FS / ºC |
| Humidity and dew point humidity | 90% RH, no condensation |
| IP Grade | IP68 |
| Rod Material | stainless steel |
| Electronic warehouse | aluminum alloy |
| Rod pressure | ≤ 34MPa |
| Position Magnetic Ring | magnetic ring |
| Pressure port | screw thread |
| Electrical connection | direct lead |
| Repeatability | ± 0.008% FS |
